Details:

Chosen by many dentists and veterinarians, the Electron (ART-E1) Electrosurgery Unit is a stand-alone device used for cutting and coagulating.
It has 10 power level settings and 3 operating modes: Cut, Coag 1, and Coag 2.

The grounding plate (included) is required for operation.

ISO and CE Certified
510k registered

Device Name: Electron

Model number: ART-E1

Part Numbers:

• 110V Model Part Number: E1-1-ART-A1-70-0
• 220V Model Part Number: E1-2-ART-v-A1-70-0

Electron (ART-E1) Warranty:

• PC Board: 1-year limited warranty
• Hand Piece: 1-year limited warranty
• Power Cord: 1-year limited warranty
• Foot Switch: 90-day limited warranty
• Electrodes: 90-day limited warranty
• Indifference/ Grounding Plate: 90-day limited warranty

Included Parts & Accessories:

• Electron (ART E1) Main Unit
• Power Cord
• PP0031-002: Universal foot switch
• EU0004-002: Indifference/ Grounding plate
• EU0003-032: E1 hand piece
• TE0002-002: Assorted electrode set of 7 (includes the following electrodes):
  • TE0001-012: T1 Diamond shaped electrode
  • TE0001-022: T2 Small loop electrode
  • TE0001-032: T3 Large loop electrode
  • TE0001-042: T4 Fine wire electrode
  • TE0001-052: T5 Heavy wire electrode
  • TE0001-072: T7 Oval loop electrode
  • TE0001-092: T9 Heavy ball electrode

Other Parts:

• EU0013-002: Bipolar converter (not included). The bipolar converter does not convert the system to operate in bipolar mode. It merely allows bipolar prongs and hand pieces to be used with the ART-E1

Specifications:

• Maximum power output: 50W (@ 400 ohm load)
• Power supply: 110V±5% ~50/60Hz 92VA or 220V±5% ~50/60Hz 92VA
• Work frequency: 1.5~1.7MHz±5%
• Dimension (cm): 23(L) x 22.5(W) x 8.5(H)
• Hand piece cable length: 190 cm
• Indifference plate cable length: 190 cm
• Weight: 12lbs
